The Ultimate Controller for Any Pond.

The ProfiLux 3 Outdoor has been designed for outdoor use (Protection Class IP 54), specially for ponds and swimming pools.

It is also suitable for professional use in aquariums.

It offers all functions of the ProfiLux 3.1T.

In addition, each a conductance and a redox module are integrated. Additional measuring inputs (eg. oxygen) can easily be added.

The ProfiLux Outdoor also offers:

  • A heated interior
  • practical and sealing cable feedthrough through the housing
  • An integrated 4.3 touch display for operation and status monitoring
  • By the housing protected expansion modules, sensor connections and dosing pumps (dosing pump heads not included)
  • 5 freely programmable splash-proof sockets (IP54)
  • 2 expansion slots
  • 4 inputs for level and leakage measurement
  • 1 slot for an optional SMS Module

The integrated power outlets and pumps can be switched manually via key pads.

ProfiLux 3 Outdoor

Connections of the ProfiLux 3 Outdoor:

ProfiLux 3 Outdoor Connections

Features of the ProfiLux 3 Outdoor:

General
Dimensions WxDxH: 340x400x115 mm (+ W right with opened cover and/or socket 50 mm/ + H below cable gland without cable 25 mm; with cable 50 mm by highest,possible bending radius) connection cable length: 1500 mm
Delivery inclusive Water Temperature Sensor Pond, USB Cable
Measurement and Control
pH-Value
Water Temperature
Redox Potential
Conductivity
Oxygen Optional (Expansion Card can be retrofitted)
Relative Humidity Optional (Expansion Card can be retrofitted)
Air Temperature
Optional (Expansion Card can be retrofitted)
Functions and Features
Lighting Control Channels 32
1-10 V Interfaces 6 (optional 30)
Controllable, separately switchable Sockets 64
Expansion Slots 2
Dosing Pump Control
Flow Pump Control
RS232 Interface
USB Interface
LAN Interface
Alarm √, visually and acoustically
Inputs Level Sensors/ Leakage Detectors 4 (optional 16)
Grafical Display
PAB Connection
Expansion Box extension possible
Integrated Webserver and Email Client
Cloud Service myGHL
Operating System ProfiLuxOS
