ProfiLux 4.1

$629.90

ProfiLux 4.1 aquarium controller with with integrated modules for temperature, pH, redox/ORP, and conductivity (fresh/saltwater switchable). WiFi, LAN (Ethernet), and USB. OTA firmware updates over WiFi or LAN. 32-channel illumination control, 16-channel pump control. Three Expansion Card slots and PAB.

Wishlist
Category: SKU: PL-2414-VAR

Description

The ProfiLux 4.1 puts ambitious aquarists in complete control of every aspect of their aquarium. Integrated measurement modules for temperature, pH, redox/ORP, and conductivity (switchable fresh/saltwater) monitor your water continuously – with alarm functions and data logging included as standard.

The 32-channel lighting control simulates clouds, storms, moon phases, seasonal changes, and natural sunrises and sunsets. Combined with dimmable GHL lights, it creates a vivid lighting environment that promotes the species-specific behavior of your animals.

The ProfiLux 4.1 connects via WiFi, LAN (Ethernet), and USB – for maximum flexibility in choosing the most reliable connection. The wired LAN port delivers the stable network connectivity that demanding installations require. OTA firmware updates are applied wirelessly or via network – no USB cable needed. Via the GHL Connect app, the built-in webserver, or the myGHL cloud service, you have access to your aquarium at any time. GHL Connect and GHL Control Center work fully locally – no internet connection, no cloud dependency.

ProfiLuxOS – GHL’s operating system developed specifically for aquarium control – runs the controller around the clock. Not a general-purpose OS adapted for aquariums, but one built from the ground up with a single goal: keeping your aquarium safe.

The ProfiLux Aquatic Bus (PAB) connects Powerbars, GHL Dosers, and Expansion Boxes reliably over cable lengths of up to 100 meters. Three expansion card slots allow retrofitting of additional measurement inputs for pH, redox, conductivity, and more. For precise dosing, continuous alkalinity monitoring, or ion measurement, GHL Doser, KH Director, and ION Director integrate seamlessly via PAB. Developed and manufactured in Germany.

Additional information

Weight 1.75 kg
Dimensions N/A
Color

White, Black

Country Version

DE, Schuko, UK, CH, AUS, USA

WEEE-Reg.-Nr.

DE96760492

Dimensions

W x D x H: 220 x 150 x 55 mm

Delivery includes

Power supply, digital water temperature sensor (lab grade), USB cable, Null-plug

Graphical display

Yes

Illumination Channels

32

1-10 V Interfaces

6 (optional 30)

Controllable, separately switchable Sockets

64

Dosing Pump Control

Yes

Stream Pump Control

Yes

Level

Yes

Automatic water change

Yes

Controls GHL automatic feeder

Yes (accessory required)

USB / RS232

Yes / Yes

WiFi / LAN

Yes / YES

Webserver / Email-Client

Yes / Yes

Alarm

Visually / acoustically

Expansion slots

3 (1x internal)

Input for pH-value sensor

Yes

Input for Water-Temperature-Sensor

Yes

Air Temperature

Optional

Redox / ORP

Yes

Conductivity

Yes

Oxygen

Optional

Relative Humidity

Optional

Expansion Box extension possible

Yes

KH / Alkalinity

Optional

Ion-selective measurement for Ca, Mg, K, Na, NO3

Optional

Inputs Level Sensors / Flow Sensors / Leakage Detectors

4 (optional 16)

Sensors included

Water Temperature

Mitras Lightbar Interface

Yes

ProfiLux Aquatic Bus (PAB)

Yes

Operating System

ProfiLuxOS

Power failure monitor port

Yes

Cloudservice myGHL

Yes

DCF Receiver port

Yes

Digital outputs / Switch channels

8 (optional 64)

GHL Control Pad port

Yes

AUX Port

Yes

Scope of delivery

These items are included:

  • ProfiLux 4.1 controller
  • Power supply (country-specific)
  • Digital water temperature sensor (lab grade)
  • USB cable
  • Null-plug

Product dimensions

L × W × H: 220 × 150 × 55 mm / 8.66″ × 5.91″ × 2.17″
