Powerhub 1 IL (7HU)

Powerhub 1 IL (7HU)

369,90 €

Includes 19% VAT
plus shipping
Delivery Time: 14 working days (may vary abroad)

Industrial Line slide-in unit (7HU) for power switching within the ProfiLux ecosystem. 6 individually controllable relay outputs on a single removable Phoenix contact terminal block. Integrated switch with 15A fuse protection. Connected and controlled via PAB (ProfiLux Aquatic Bus).

For the full product page, visit:

https://www.aquariumcomputer.com/products/industrial-line/

Manufacturer: GHL Advanced Technology GmbH & Co. KG
Marie-Curie-Straße 20
67661 Kaiserslautern
Germany
Wishlist
Categories: , SKU: PL-2107

Description

The Powerhub 1 IL brings ProfiLux-controlled power switching into your Industrial Line rack. Six relay outputs let you switch equipment such as pumps, heaters, UV sterilizers, or lighting on and off – fully automated through your ProfiLux controller, just like the well-known GHL Powerbar, but designed for professional rack-mounted installations.

All outputs are routed to a single removable Phoenix screw terminal connector, carrying L, N, PE, and the six switched lines. This makes wiring clean and service-friendly: disconnect the terminal block, and the entire unit can be removed or replaced without rewiring.

The integrated rocker switch includes a 15A fuse that protects the combined load of all outputs. Connection to the ProfiLux controller is made via PAB cable – no additional configuration beyond the standard Powerbar setup in GHL Connect.

An optional GHL Logo Frontpanel IL (5HU) can be connected to the unit’s RGB logo port for visual system status indication.

Additional information

Shipping weight 1 kg
Shipping dimensions 34 × 15 × 15 cm

Scope of delivery

These items are included:

  • Powerhub 1 IL slide-in unit
  • Removable Phoenix terminal connector

Product dimensions

L × W × H: 295 mm × 69.6 mm × 82 mm (11.6″ × 2.7″ × 3.2″)

Warnings and safety information:

This product is intended exclusively for use in aquariums, terrariums, or similar applications. It must not be used for other purposes.
Not suitable for children or unattended operation. For indoor use only.

Always ensure proper installation and regular maintenance according to the included safety instructions. There is a risk of electric shock if the product is installed or used incorrectly.

Before installation, cleaning, or maintenance, always disconnect the product from the power supply.
For detailed safety, maintenance, and disposal information, please refer to the printed safety documentation provided by GHL Advanced Technology GmbH & Co. KG.
